Question 1

Why can't we just use adhesive on plant and machinery?

Accepted Answer

Because it will fail, usually within a year. Machinery surfaces carry an oil film that no adhesive bonds through reliably, vibration works at the edges of a tag continuously, and pressure washing finishes it. A mechanically fixed tag is the only one that lasts the service life of the equipment.

Question 2

How much do riveted tags cost?

Accepted Answer

They are quoted on specification rather than listed, because thickness, hole configuration and size vary more than on our standard products. Send us the equipment types and quantities and we come back within four working hours.

Question 3

What hole sizes can you punch?

Accepted Answer

We punch to your fastener. Tell us the rivet diameter you use and we match it. If you have not chosen a fastener yet, tell us the equipment and we will recommend one and supply it with the tags.

Question 4

Do you supply the rivets and the rivet gun?

Accepted Answer

Yes to both. Most organisations already have a rivet gun in the workshop, but if not we can supply one with the order so the tagging is not held up waiting for a tool.

Question 5

How many holes should a tag have?

Accepted Answer

Two, at opposite ends, for almost everything. A single rivet lets the tag rotate, which eventually wears the hole and loosens it. Four holes on larger tags in high-vibration positions. We will specify based on where the tag is going.

Question 6

Can riveted tags go on equipment that is under warranty?

Accepted Answer

Drilling into equipment can affect a warranty, so check the terms first. In practice we usually find an existing hole, a bracket, a guard or a non-structural panel to fix to. Tell us which equipment is under an active service contract and we will work around it.

Question 7

Can our own workshop fix these, or do you have to?

Accepted Answer

Your workshop can, easily, it is drilling and riveting, not specialist work. What matters more is consistency of placement, so that every grader has its tag in the same position and a verification sweep is not a treasure hunt. We supply a placement guide with the order.

Question 8

Is riveting the only option for oily machinery?

Accepted Answer

It is the reliable one. Acetone-activated tags will hold on a cleaned, flat control panel or housing, and we often specify that for the clean parts of a machine and riveted tags for the dirty ones. But if the surface cannot be got properly clean and kept clean, rivet it.

Question 9

How long do riveted tags last?

Accepted Answer

Longer than the adhesive question makes relevant, the tag is anodised aluminium, so 9+ years outdoors and typically the full service life of the machine. The failure mode for a riveted tag is the equipment being scrapped, not the tag coming off.

Question 10

Can we rivet onto scaffolding and small components?

Accepted Answer

Onto scaffolding tube, usually not, there is no flat face and the wall is thin. Scaffolding is normally managed by count rather than individually, unless you are hiring it out. For hire fleets we would look at a banded or welded plate instead, and we will advise rather than sell you the wrong product.

Tag type	From	Best for
Aluminium Barcode	KSh 50excl. VAT	general assets
Aluminium QR Code	KSh 55excl. VAT	QR workflows
Acetone-Activated	KSh 60excl. VAT	permanent bonds
Tamper-Evident	KSh 55excl. VAT	tamper evidence
Polyester / Vinyl Barcode	KSh 35excl. VAT	indoor assets

Up to 200	Same-day production
Up to 1,000	2 working days
Up to 5,000	3–5 working days
Over 5,000	Confirmed on quotation

Specification	Details
Material	Anodised aluminium
Thickness	0.5 mm (heavier gauge on request)
Fixing	Pre-punched holes to your fastener size; rivets and rivet gun available
Sizes	Standard sizes and custom to 300 × 200 mm
Operating temperature	-40°C to +120°C (-40°F to +248°F)
Expected outdoor life	9+ years under normal outdoor conditions, subject to UV exposure, chemical exposure, installation surface and the marking/adhesive system used.
Encoding	Code 128, Code 39, QR Code, Data Matrix
Minimum order	100 pieces

Size	Best for	Price per tag
39 × 13 mmAnchor price	Compact, laptops, small electronics, instruments	Quotation on request
50 × 20 mm	Most popular, general fixed assets	Quotation on request
50 × 30 mm	Larger barcode, easier scanning at distance	Quotation on request
35 × 35 mm	Square, best for QR codes	Quotation on request
60 × 30 mm	Maximum data, logo and text	Quotation on request

	Riveted	Acetone-activated
Price	Quotation on request	From KSh 60 excl. VAT
Fixing	Mechanical, rivets or screws	Chemical bond into the surface
Oily surfaces	Works	Needs a clean, dry surface
Vibration	Unaffected	Can fail over years of heavy vibration
Asset must allow drilling	Yes	No

Riveted asset tags
